Particles ================== In this chapter, we will cover the implementation of particles in RAMSES, namely: - How particles are represented in the code - How we can we navigate the list of particles in the code - How particles interact with the grid .. contents:: 1. Particles implementation in RAMSES ------------------------------------- 1.1 Particle arrays ~~~~~~~~~~~~~~~~~~~ The core of the particle-related code is stored in the ``pm`` folder, where PM stands for "particle-mesh" (i.e., the part of the code responsible for interactions between the particles and the mesh). As for other parts of the code, the majority of the important variables are stored in a *commons* module. For the particles, the module is ``pm_commons``, found in ``pm/pm_commons.f90``. Additional variables are stored in the corresponding ``pm_parameters`` module, located in ``pm/pm_parameters.f90``. Most quantities related to particles are stored in large **global arrays**, with in general one variable per array. The size of these arrays is fixed by the maximum number of particles allowed for the run, set by the parameter ``npartmax`` defined in the ``pm_parameters`` module. We will cover how to set this parameter in :doc:`the section on the namelist `. Just like ``ngridmax`` for the grids, the number of particles can either be set directly through ``npartmax`` (which sets the maximum number of particles *per MPI process*), or through the *total* number of particles across all MPI processes, ``nparttot``. These two are related through ``nparttot = npartmax*ncpu``. .. warning:: It is usually more convenient to work with ``npartmax`` when developing code, as it is the actual size of the arrays available for each MPI process. However, when running a simulation with a fixed number of particles (e.g., a dark matter-only simulation), ``nparttot`` might be more convenient. The particle masses are stored in the ``mp`` variable, which is a one-dimensional array of size ``npartmax``. The positions and velocity are stored in ``xp`` and ``vp``, respectively: these are two-dimensional arrays, with size ``(npartmax, ndim)`` where ``ndim`` is the number of dimensions (usually ``ndim=3``). Similar arrays exist for the birth time, the metallicity, or the AMR level at which the particles are living. All these arrays are defined in ``pm/pm_commons.f90``: .. code:: fortran ! Particles related arrays real(dp),allocatable,dimension(:,:) ::xp ! Positions real(dp),allocatable,dimension(:,:) ::vp ! Velocities real(dp),allocatable,dimension(:) ::mp ! Masses ... real(dp),allocatable,dimension(:) ::tp ! Birth epoch real(dp),allocatable,dimension(:) ::zp ! Birth metallicity ... integer ,allocatable,dimension(:) ::levelp ! Current level of particle 1.2 Different types of particles ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ While RAMSES was originally (`Teyssier, 2002 `__) designed to work with only DM particles, the code was quickly extended to star formation, galactic winds, black holes, etc. All these developments have relied, to some extent, on "particles": for example, stars are modelled as particles representing a stellar population with a unique age and metallicity. In practice, the choice in RAMSES is that all these "particles" are implemented using the same global arrays: ``xp`` for positions, ``mp`` for mass, etc. However, this requires some adjustments to identify which particle correspond to what type of thing. For example, some physical models such as supernova explosions only apply to star particles, and we therefore need a simple way to identify which particles corresponds to stars, and which don't. Since 2017, RAMSES implements these as *particle types* (similar, for example, to Gadget/AREPO particle *types*), stored in the ``typep`` array. Contrary to other arrays we have seen so far, ``typep`` is not an *simple* array with real/integer values, instead it is an array of ``part_t``, a *derived type* that contains two variables, defined at the end of ``pm/pm_parameters.f90``: - a ``family`` variable - a ``tag`` variable The ``typep`` variable is defined in ``pm/pm_commons.f90``: .. code:: fortran type(part_t), allocatable, dimension(:) :: typep ! Particle type array and the type itself is defined in ``pm/pm_parameters.f90``: .. code:: fortran type part_t ! We store these two things contiguously in memory ! because they are fetched at similar times integer(1) :: family integer(1) :: tag end type part_t The ``family`` variable stores what the particle represent: +----------------+-------+-------------------------------------------------------------+ | Family | Value | Physical meaning | +================+=======+=============================================================+ | ``FAM_DM`` | 1 | DM particle | +----------------+-------+-------------------------------------------------------------+ | ``FAM_STAR`` | 2 | Star particle | +----------------+-------+-------------------------------------------------------------+ | ``FAM_CLOUD`` | 3 | "Cloud" particle, used for some black-hole implementations | +----------------+-------+-------------------------------------------------------------+ | ``FAM_DEBRIS`` | 4 | "Debris" particle, used for some supernovae implementations | +----------------+-------+-------------------------------------------------------------+ | ``FAM_OTHER`` | 5 | "Other" type of particle, defined as a catch-all value | +----------------+-------+-------------------------------------------------------------+ | ``FAM_UNDEF`` | 127 | Used for "undefined" type, internally | +----------------+-------+-------------------------------------------------------------+ In addition, six other values are used for *tracer* particles, mirroring values in the table above (e.g., ``-1`` for DM tracers, ``-2`` for star tracers, etc), as well as a ``FAM_TRACER_GAS=0`` value for gas tracer particles. The particle tags are currently not commonly used, but allow flexibility to have different types of *the same kind* of particles. For example, one could decide to have Pop III stars and normal Pop II stars implemented at the same time: both would be considered as *stars* by the code (``FAM_STAR`` family), but still identified independently with their own tag. This can be useful either for post-processing (e.g., "make a map of all Pop III stars"), or even for specific physical models (e.g., Pop III stars could have a different radiative output or stellar evolution model). In practice, rather than testing directly the ``typep`` value of a particle, the best practice is to use the *functions* defined at the end of the ``pm_commons`` module to test whether a particle is of a given type. For example, the ``is_star`` function returns ``True`` if the particle is a star, and ``False`` otherwise. This allows more concise code, as we can write multiple tests in one function. For example, ``is_tracer`` returns ``True`` if a particle is a tracer particle, *irrespective of what kind of tracer*. NB: when implementing new types of particles, make sure to use the right ``family`` (if one already exists), use or define the appropriate ``tag``, and (if necessary) add the right tester function. 1.3 Initialising particles ~~~~~~~~~~~~~~~~~~~~~~~~~~ In the code, the global particle arrays are *defined* in the ``pm_commons`` module, but are not *allocated* there: indeed, ``npartmax`` is a runtime parameter, so it cannot be fixed once and for all in the code. Instead, all the particle-related arrays are allocated when the simulation is initialised, in the ``init_part`` routine, defined in ``pm/init_part.f90``. This is done through the following code: .. code:: fortran ! Allocate particle variables allocate(xp (npartmax,ndim)) allocate(vp (npartmax,ndim)) allocate(mp (npartmax)) By default, all these arrays are set to 0 prior to proper initialisation. Then, depending on whether the code is starting from initial conditions or re-starting from a previous output, the variables are set to the right values. When **starting from initial conditions**, three formats are supported by default: ASCII files, GRAFIC files, and GADGET files. We will not cover the inner details of each of these formats, but the corresponding subroutines (``load_ascii``, ``load_grafic``, and ``load_gadget``) can all be found in ``pm/init_part.f90``. The easiest to understand is ``load_ascii``, but they all work in similar ways: #. we read the input file header to deal with units, box size, etc #. we read all arrays in the input file and count the number of particles #. (we communicate information across MPI processes) #. while iterating over particles, we fill the global arrays (``xp``, ``vp``, ``mp``, etc). .. admonition:: **Exercise** Can you explain how the ``load_ascii`` and ``load_grafic`` subroutines work? For example, can you identify where the positions are read, and where they are set in the ``xp`` array? In the case of a **restart**, the process is roughly the same, except that each MPI process opens the corresponding file from the last output. For example, if we restart from output 42, the MPI process 37 will open the file ``output_00042/part_00042.out00037``. .. warning:: This strategy to initialise the data at restart is part of the reason why RAMSES enforces that the number of MPI processes stays identical when restarting a simulation. .. admonition:: **Exercise** Identify where, in ``init_part.f90``, the particle output files are opened. .. admonition:: **Solution** :class: dropdown Look around ``if(nrestart>0) then``: .. code:: fortran call title(nrestart,nchar) fileloc='output_'//TRIM(nchar)//'/part_'//TRIM(nchar)//'.out' ... call title(myid,nchar) fileloc=TRIM(fileloc)//TRIM(nchar) ... open(unit=ilun,file=fileloc,form='unformatted') The ``title`` function transforms the output number ``nrestart`` or the MPI process ID ``myid`` to a string padded with five ``0``. Once the file is open, we first read a header and then, each array stored in the output will be read. For example, the positions are read as: .. code:: fortran ! Read position allocate(xdp(1:npart2)) do idim=1,ndim read(ilun)xdp xp(1:npart2,idim)=xdp end do Let's explain how these lines work. First, we allocate a temporary array (``xdp``) with size ``npart2`` corresponding to the number of particles *in the file*. Then, for each dimension, we read the position from the file to the array ``xdp``, and we fill the position array ``xp`` with the array we just read. Note that we use and re-use several temporary arrays (``xdp``, ``isp8``, ``isp``, ``ii1``), each corresponding to a data type. .. warning:: **Careful:** if you change the output format for the particles, you will need to change the section of ``init_part.f90`` that deals with restarts. 2. Navigating particle arrays with linked lists ----------------------------------------------- Because of the AMR structure of RAMSES, we need to store particles in a structure that can efficiently be connected to the grid. As the grid evolves with time, this structure also needs to evolve with time. The "natural" solution for this is to use a linked-list for the particles, just like what is done for the grid. The key idea here is that particles living in the same grid are linked together with a linked-list that is defined *per-grid*, and we use the grid structure with its own linked list to connect all the particles together. As this leads to a tree structure, the bulk of the code dealing with the particle list is in the aptly named ``pm/particle_tree.f90`` file. 2.1 Particle linked list structure ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ In each grid, we have a particle linked list defined using the following variables, defined in ``pm/pm_commons.f90``: .. code:: fortran integer ,allocatable,dimension(:) ::headp ! Head particle in grid integer ,allocatable,dimension(:) ::tailp ! Tail particle in grid integer ,allocatable,dimension(:) ::numbp ! Number of particles in grid They are allocated in the ``init_amr`` subroutine (in ``amr/init_amr.f90``), if the run parameter flag ``pic`` (particle in cell) is set: .. code:: fortran if(pic)then allocate(headp(1:ngridmax)) allocate(tailp(1:ngridmax)) allocate(numbp(1:ngridmax)) headp=0; tailp=0; numbp=0 endif Note that if ``pic`` is *not* set, there are no particles, so we don't have to do any of this. As required for a linked list, for each particle the next and previous particle in the list is stored. These arrays are defined in ``pm/pm_commons.f90``: .. code:: fortran integer ,allocatable,dimension(:) ::nextp ! Next particle in list integer ,allocatable,dimension(:) ::prevp ! Previous particle in list They are allocated in ``pm/init_part.f90``: .. code:: fortran allocate(nextp (npartmax)) allocate(prevp (npartmax)) One specificity of particles is that they can move freely through the AMR grid: they can enter and exit cells during a timestep, and (because of the timestepping strategy), they can move to grids that live on different timesteps. Dealing with this requires careful consideration, and the subroutines dealing with this are found in ``pm/particle_tree.f90``, with the most important one being ``make_tree_fine``. It essentially detaches particles that have moved from their original parent grid, and reattaches them to the grid in which they are now located. Similarly, when a grid is refined or derefined, special care needs to be taken of the particles: the routines doing this are, respectively, ``kill_tree_fine`` and ``merge_tree_fine``. Finally, when particles move across processor boundaries (see the :doc:`section on MPI communications `), the routine ``virtual_tree_fine`` deals with the linked list structure. 2.2 Iterating over particles ~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The *particle* and *grid* linked lists structures are used to iterate over particles. The following code block represents the usual way of looping over all particles in a given MPI process: .. code:: fortran do icpu=1,ncpu ! Loop over cpus igrid=headl(icpu,ilevel) ! Loop over grids do jgrid=1,numbl(icpu,ilevel) npart1=numbp(igrid) ! Number of particles in the grid if(npart1>0)then ipart=headp(igrid) ! Loop over particles do jpart=1,npart1 ! Save next particle <--- Very important !!! next_part=nextp(ipart) !---- ! Do something with particle ipart !---- ipart=next_part ! Go to next particle end do endif igrid=next(igrid) ! Go to next grid end do end do Let's unravel this and start from the ``igrid = headl(icpu, ilevel)`` line. This initialises the variable ``igrid`` to the index of the first element of the list of *grids* at the current level ``ilevel``. Then, the section .. code:: fortran do jgrid=1, numbl(icpu, ilevel) npart1=numbp(igrid) ... igrid=next(igrid) end do loops over all grids at the current level. The variable ``npart1=numbp(igrid)`` stores the number of particles that exist in grid indexed by ``igrid``. Note here that when we first enter the loop, ``igrid`` is defined from the ``headl`` access, but at the end of the loop, we go to the next grid in the list, determined by ``next(igrid)``. If there is at least one particle in the grid (i.e., if ``npart1>0``), we can loop over the particles in the grid with the particle linked-list: .. code:: fortran ipart=headp(igrid) do jpart=1,npart1 next_part=nextp(ipart) ... ipart=next_part end do This is done in many places in the code, and looking for the ``Very important !!!`` comment is likely to return many of these places. You can guess how people usually go about writing this loop. 2.3 Adding and deleting new particles ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Multiple routines in RAMSES need to create or destroy particles. Once again, the most typical example is the star formation routine: when new stars are formed, we need to "spawn" new particles and update the linked lists accordingly. Conversely, it can happen that particles are destroyed (for example, the "cloud particles" surrounding black holes when two black holes merge). This is handled by routines found in ``pm/add_list.f90`` and ``pm/remove_list.f90``. Let's quickly review how they work together. When spawning new particles, we need to insert them somewhere in the particle linked list. This is done relatively easily thanks to the linked list structure: we just need to add the particle index after the current last particle in the ``nextp`` array. This is essentially what the ``add_list`` subroutine does in ``pm/add_list.f90``: .. code:: fortran nextp(tailp(ind_grid(j))) = ind_part(j) Here, ``tailp(ind_grid(j))`` indicates the tail of the particle linked list in the grid ``ind_grid(j)``, and we define the ``nextp`` particle as the one with index ``ind_part(j)``. To make sure that there is enough space in the particle arrays, we need to use the ``remove_free`` subroutine of ``pm/remove_list.f90``, which essentially reserves a block of the particle arrays for the new particles. As a result, the correct way to update the linked lists when adding new particles is **always** to *first* call ``remove_free``, then add the particles with ``add_list``. This is for example done in the star formation routine in ``pm/star_formation.f90``: .. code:: fortran ! Update linked list for stars call remove_free(ind_part,nnew) call add_list(ind_part,ind_grid_new,ok_new,nnew) 3. Cloud-in-Cell scheme ----------------------- Particles interact with the rest of the simulation in essentially two ways: either through direct exchange of mass, energy, momentum, radiation (…) with the grid, or through their gravitational influence. The former will be discussed in the section on :doc:`subgrid modelling `, and we will now focus on the way particles interact with gravity. CIC is a general mapping between grids and particles: it can be used beyond gravity (e.g., for sink particles accretion). As discussed in the section on :doc:`subgrid modelling `, other assignment schemes are used for feedback, for example. 3.1 Overview ~~~~~~~~~~~~ As already discussed in the :doc:`general review of the code `, (massive) particles act as a source term for gravity: they contribute to the density field :math:`\rho`. This field is represented in the code by the ``rho`` array, which is defined *for each cell*. In order for particles to contribute to the density field, we need a method to distribute their mass on the grid. RAMSES does this through the **cloud-in-cell** scheme, or **CIC**. The idea is to distribute the mass of each particle in a cloud with cubic shape (in 3D): unless the particle is perfectly at the centre of a cell, its cloud will overlap with other cells, and the mass of the particle will be spread over those cells depending on the volume fraction of the overlapping region. |cic_octree1| |cic_octree2| .. octree1 octree2 In more details: a particle that "lives" at a level ``ilevel`` will be represented as a cube with side length :math:`\Delta x = L/2^{\texttt{ilevel}}`, and its volume will therefore be :math:`\Delta x^{\texttt{ndim}}`, usually :math:`\Delta x^3`. We can show that the cloud will overlap with :math:`2^{\texttt{ndim}}` grid cells. In order to compute the contribution of a particle to each of the overlapping cells, we need: - the indices of the cells with which the particle overlaps - the overlapping sub-volume of the particle cloud with these cells. In practice, the second part is done before the first: the sub-volumes are calculated as rectangular cuboids, using the distances to the cell boundaries ``dd`` and ``dg`` (respectively for *distance droite* and *distance gauche*). 3.2 Walking through ``cic_amr`` ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ To better understand how the CIC scheme is applied, let's look at the ``cic_amr`` routine that can be found in the ``pm/rho_fine.f90`` file. After some book-keeping, we recover the neighbouring father cells with .. code:: fortran call get3cubefather(ind_cell,nbors_father_cells,ng,ilevel) This will be needed to get the grid index of all the neighbours. We then rescale all the positions at the current level to get the position of the 3×3×3 neighbour grids (in 3D), rescaled to be between 0 and 6 in each dimension. .. code:: fortran ! Rescale particle position at level ilevel do idim=1,ndim do j=1,np x(j,idim)=xp(ind_part(j),idim)/scale+skip_loc(idim) x(j,idim)=x(j,idim)-x0(ind_grid_part(j),idim) x(j,idim)=x(j,idim)/dx end do end do This is then the time to get the particle properties that we may want to dump on the grid, for example the mass of non-tracer particles. This is done by reading the particle mass ``mp`` in the ``cic_amr`` routine, but we could do the same thing for other extensive quantities (e.g., metal mass). After some extra checks, we then compute ``dd`` and ``dg`` along each dimension. The volume of each of the sub-volumes is computed from the values of ``dg`` and ``dd``. For example, in two dimensions: .. code:: fortran #if NDIM==2 do j=1,np vol(j,1)=dg(j,1)*dg(j,2) vol(j,2)=dd(j,1)*dg(j,2) vol(j,3)=dg(j,1)*dd(j,2) vol(j,4)=dd(j,1)*dd(j,2) end do #endif Particle ``j`` will have a fraction of its cloud volume in cell #1 given by ``dg(j,1)*dg(j,2)``, the fraction in cell #2 given by ``dd(j,1)*dg(j,2)``, and so on. All these are stored in the array ``vol(:,:)``, where the first dimension corresponds to the particle, and the second to the sub-volume. Once this is all computed, we need to assign these sub-volumes to the relevant cells. |cic_grid_index| First, we need to identify the local index of the parent grid. During the ``dd`` and ``dg`` computation, we get the index of the left and right boundaries in ``ig`` and ``id``, respectively. As the parent grid lives on level ``ilevel-1``, the corresponding local) grid indices (``igg`` and ``igd``, for index grid *gauche* and index grid *droite*) will be halved: .. code:: fortran do idim=1,ndim do j=1,np igg(j,idim)=ig(j,idim)/2 igd(j,idim)=id(j,idim)/2 end do end do On the figure above, this corresponds to computing the local grid index from the local position. From there, we compute an index ``kg`` for each of the 8 sub-volumes, which is used to determine the *global* grid index ``igrid`` of that parent grid: .. code:: fortran do ind=1,twotondim do j=1,np igrid(j,ind)=son(nbors_father_cells(ind_grid_part(j),kg(j,ind))) end do end do We then need to determine which of the 8 cells belonging to the parent grid is relevant, i.e., which is the local ``ind`` (as defined in the section on :doc:`AMR structure `). This is done again by index arithmetics, depending on the values of ``ig``, ``id``, ``igg``, and ``igd``, and yields the array ``icell(:,:)`` where the first dimension corresponds to the particle on which we are working, and the second to the 8 sub-volumes. We *finally* can compute the global cell index as .. code:: fortran ! Compute parent cell adress do ind=1,twotondim do j=1,np indp(j,ind)=ncoarse+(icell(j,ind)-1)*ngridmax+igrid(j,ind) end do end do Once all of this is done, we can loop over the particles to do something with the CIC scheme. For example, in ``cic_amr``, we compute the contribution of the particles to the density array ``rho``: we first define the "mass fraction" ``vol2``: .. code:: fortran do j=1,np ok(j)=(igrid(j,ind)>0).and.is_not_tracer(fam(j)) vol2(j)=mmm(j)*vol(j,ind)/vol_loc end do and then increment ``rho`` with it: .. code:: fortran do j=1,np if(ok(j))then rho(indp(j,ind))=rho(indp(j,ind))+vol2(j) end if end do 3.3 Details of the CIC density calculation ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ If we look more carefully at the main loop where the density field is computed, we can note several things. .. code:: fortran if(cic_levelmax==0.or.ilevel<=cic_levelmax)then do j=1,np if(ok(j))then rho(indp(j,ind))=rho(indp(j,ind))+vol2(j) end if end do else if(ilevel>cic_levelmax)then do j=1,np ! check for non-DM (and non-tracer) if ( ok(j) .and. is_not_DM(fam(j)) ) then rho(indp(j,ind))=rho(indp(j,ind))+vol2(j) end if end do endif if(ilevel==cic_levelmax)then do j=1,np ! check for DM if ( ok(j) .and. is_DM(fam(j)) ) then rho_top(indp(j,ind))=rho_top(indp(j,ind))+vol2(j) end if end do endif First of all, for DM particles, CIC assignment is only done if the level is below ``cic_levelmax``. Otherwise, a different array, ``rho_top`` is updated. This is a way of dealing with the fact that DM particles are usually much more massive than the baryons in the simulation. In practice, this "smooths" the DM particles to the level ``cic_levelmax``, which is a free namelist parameter. .. warning:: A good way of choosing ``cic_levelmax`` is to run a DM-only simulation, and see what is the maximum level of refinement that is reached. This will be the natural smoothing level for the DM particles, and avoids dumping all the DM particle mass in a small cell (whose size is determined by its baryonic content rather than DM content). This is note done for non-DM particles: indeed, they are expected to "live" at the finest grid level. Second, we can also note that CIC is used in several places. - ``cic_amr`` called from ``rho_from_current_level``, itself called in ``rho_fine``, which calculates the density field of the particles. - ``cic_cell`` called from ``cic_from_multipole`` which represents the gas cells as *pseudo-particles* to calculate the gas density field (used as input for the gravity calculation) in the same way as the particles. This has some advantages. - ``cic_only`` called from ``rho_only_level`` in the clumpfinder, to calculate the density field on which to perform the clump finding. While all these routines are pretty similar, this leads to a lot of code duplication, which can *sometimes* be hard to maintain. There is work being done on this, but it takes time. Also, RAMSES has an alternative to the CIC scheme that is in principle more accurate: the TSC scheme, for *triangular-shaped cloud*. This is a smoother, more expensive, assignment scheme. .. admonition:: **Exercise** Go through the code for the TSC scheme. What is different about it? 3.4 Inverse CIC: grid affecting the particles ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ As we have seen in the :doc:`gravity section `, once the Poisson equation has been solved, we need to update the particle positions and velocities. As the acceleration (from the gravitational field) is only known at the grid position, we need to interpolate it at the particle positions. This is done using the same type of CIC scheme as for the density calculation, except that instead of changing a quantity on the grid, we read the updated force at the particle location. Just like previously, we need: - the identity of each neighbouring cell - the fraction of the particle cloud in each neighbouring cell - the contribution of each of these cell to the acceleration Note that special care must be taken when the particle overlaps with cells that are at a different refinement level. As an exercise, you can go through the ``sync`` routine called by ``synchro_fine`` in ``pm/synchro_fine.f90`` and ``move1`` called by ``move_fine`` in ``pm/move_fine.f90`` to go through the logic. .. |cic_octree1| image:: ./img/cic_octree1.png :height: 300px :alt: "CIC assignment" .. |cic_octree2| image:: ./img/cic_octree2.png :height: 300px :alt: "CIC weighting" .. |cic_grid_index| image:: ./img/cic_grid_index.png :alt: "Grid indexing"
